Item No

0000001000

Type
Surface grinder machine
Maker
OKAMOTO
Model
PSG-84DX
MFG Year
2007
Movie
Specification
1 2
Comment
Table working surface: 850 × 400 mm
Table travel range: 950 × 440 mm
Distance from table top to bottom of grinding wheel: 595 mm
Chuck size: 800 × 400 × 85 mm
Maximum work weight: 700 kg
T-slot width × quantity: 17 mm × 3 slots
Automatic feed increment: 0.001–0.03 mm (15 steps)
Grinding wheel (Out diax Widthx In dia): φ305x 38xφ127 mm     Grinding wheel rotation speed: 1,800 rpm

Required floor space: 3,222 x 2,214 m
Machine height: 2,114 mm
Machine weight: 3,900 kg

Overhead dresser
Grinding wheel (with flange
Dust collector・Coolant System with Magnetic Separator (120L)
Wheel balancer
Click on the picture for larger view.
*The machine condition shall be understood "AS IS", regardless of specifications and photos in the machine list.
