DETAIL
- Item No
0000001005
- Type
- NC Vertical Multitasking Lathe
- Maker
- OKUMA
- Model
- VTM-200YB
- MFG Year
- 2010
- Movie
- Specification
- 1 2
- Comment
- Maximum swing: φ2,400 mm
Maximum machining diameter: φ2,000 mm
Maximum machining length: 1,400 mm
Maximum workpiece weight (including chuck weight): 7,000 kg
Cantilever support : 110 kg/ Double center support : 500 kg
Travel X: 1,600 Y: ±800 Z: 1,400 mm
B: 120° (-15° to 105°)
C: 0.001 index
B-axis spindle NC indexing (0.001° index, 5° index combined)
Chuck rotation speed: L (low speed): 4 ～200 rpm
H (high speed): 6 ～ 400 rpm
Tool rest type : H1 (1 for L (turning) and M (rotating tool))
Spindle rotation speed (M-axis): 4,000 rpm
Tooling: BBT50 (BIG PLUS)
Magazine tool storage capacity: 36 tools
Tool post type: ATC single tool
Required floor space: 6,193 x 7,325 mm
Height: 4,745 mm
Machine weight: 35,000 kg (excluding chuck)
Controlled Axes: 5 axes (X, Y, Z, B, C)
(3 axes controlled simultaneously, excluding B)
φ2,000 mm 4-jaw indented chuck (jaw lock)
B-axis angled indexing for turning (indexing every 5°)
M-axis spindle center through coolant: 1.5 Mpa
X, Y, Z, and B-axis scale feedback
Automatic cutting edge measurement (automatic ATS) by Renishaw
Touch probe for workpiece measurement by Renishaw
Chip conveyor (hinge type)
Automatic door for workpiece removal
Tape storage capacity: 1280 m
Chamfering, corner radius
Helical interpolation
Data server: 1 GB
Spare M-codes: 4
Click on the picture for larger view.
*The machine condition shall be understood "AS IS", regardless of specifications and photos in the machine list.
