DETAIL
- Item No
0000001008
- Type
- Gate-Type Surface Grinding Machine
- Maker
- OKAMOTO
- Model
- PSG-158CH-iQ
- MFG Year
- 2011
- Movie
- Specification
- 1 2
- Comment
- Max. Workpiece Pass Width: 1,050 mm
Table Work Surface Size: 2,050 x 850 mm
Workpiece weight capacity: 3,300 kg (including 800 kg chuck)
Chuck size: 1,500 x 800 x 100 mm
Travel X: 2,250 Y: 910 Z: 620 mm
Z-axis automatic feed: 0.0001 ～ 0.9999 mm
Automatic feed increment: 0.001–0.03 mm (15 steps)
Grinding wheel (Out diax Widthx In dia): φ510 x 50 x φ127 mm
Grinding wheel rotation speed: 400 ～ 1,600 rpm
Facility Footprint: 6,570 x 3,850 mm Machine
Height: 3,550 mm
Machine Weight: 15,500 kg
Magnetic separator water injection system・ automatic paper filter ・automatic liquid temperature controller
Electromagnetic chuck (1500 x 800 mm)
Automatic demagnetization controller
Spare grinding wheel flange
Work light (LED)
Click on the picture for larger view.
*The machine condition shall be understood "AS IS", regardless of specifications and photos in the machine list.
