DETAIL
- Item No
0000001019
- Type
- CNC Lathe
- Maker
- OKUMA
- Model
- GENOS L250H （チャッカ―仕様） (S/No. 164037)
- MFG Year
- 2012
- Movie
- Specification
- 1 2
- Comment
- Control unit: OSP‑P200LA
Swing over bed: φ450 mm
Swing over cross slide: φ300 mm
Max. work dia. × max. length: φ280 × 200 mm
Stroke X: 160 mm / Z: 330 mm
Max. spindle speed: 75–3,000 rpm
Spindle through‑hole diameter: φ66 mm
Turret type: 8‑station drum turret
Required floor space: 1,625 × 1,592 mm
Machine height: 1,624 mm
Machine weight: 2,800 kg
Left‑discharge rear chip conveyor
Without taistock
Kitagawa chuck (N‑10A0601A)
Click on the picture for larger view.
*The machine condition shall be understood "AS IS", regardless of specifications and photos in the machine list.
