DETAIL
- Item No
0000001027
- Comment
- Control unit: MAZATROL SMOOTHC
Maximum swing: φ660 mm
Max.work dia.× max. work length: φ350 × 514 mm
Travel: X = 195 mm / Z = 560 mm
Maximum spindle speed: 5,000 rpm
Spindle through‑hole diameter: φ76 mm
Turret type: 12‑station drum turret
Tailstock travel: 550 mm
Required floor space: 3,630×1,980 mm
(including conveyor)
Machine height: 1,700 mm
Machine weight: 4,800 kg
8‑inch hollow chuck BB‑208 (Kitagawa)
Side‑discharge chip conveyor (front‑right discharge, hinge‑belt type)
Automatic tool setter
Powerful coolant (1.1 kW)
NC tailstock
USB I/F (2 ports)
Equipped with MAZA‑CARE system
Relocation detection device
Click on the picture for larger view.
*The machine condition shall be understood "AS IS", regardless of specifications and photos in the machine list.
