Item No

0000000959

Type
NC small hole EDM
Maker
SODICK
Model
K3HN
MFG Year
2014
Movie
Specification
1 2
Comment
Controller : LK2
Table dimensions : 400 x 450 mm
Maximum workpiece dimensions : 400 x 450 x 300 mm
Maximum workpiece weight : 200 kg
Electrode mounting diameter : φ0.25-3.0 mm
Travel X: 300 Y: 400 Z: 300 mm W: 230 mm
Distance from bottom of guide to top of table : 70-300 mm
Electric capacity : 3-phase 6.2kVA/200V

Required floor space : 1,425 x 1,120 mm
Height : 2,080 mm
Machine weight : 850 kg

W-axis NC control
Handheld operation box
Service tank external dimensions : 706x436x1,350 mm
Machining diameter : VITOL-KS
Weight : 110 kg
Tank capacity : 100 L
Machining fluid filtration method :
Paper filter replacement type HF-17 (internal pressure type)
High pressure pump: 3-phase 220V 0.75kW
High pressure pump maximum fluid pressure : 8 Mpa
Machining fluid cooling device
Click on the picture for larger view.
*The machine condition shall be understood "AS IS", regardless of specifications and photos in the machine list.
