Item No

0000000976

Type
Horizontal Machining Center
Maker
MORI SEKI
Model
NH4000 DCG
MFG Year
2006
Movie
Specification
1 2
Comment
Controller : MSX-501 (FANUC-18iMB)
Table size : 400 mm square /3 PL
Table indexing angle : 0.001° index
Load capacity : 400 kg
Max. workpiece swing dia. : φ630 mm
Travel  X : 560  Y : 560  Z : 630 mm  B : 360°
Spindle taper : BBT40 (2-sided restraints)
Spindle speed : 14,000 rpm
ATC : 120 stations

Required bed surface : 2,864×3,755 mm H : 2,830 mm
Machine weight : 9,600 kg


Renishaw touch probe
Automatic tool length measurement
Chip conveyor: Rear discharge (scraper type)
Mist collector
Helical interpolation
One-way positioning
Rigid tap
Custom macro B
Click on the picture for larger view.
*The machine condition shall be understood "AS IS", regardless of specifications and photos in the machine list.
