DETAIL
- Item No
0000000992
- Comment
- Swing above bed: 600 mm
Swing above cross feed table: 380 mm
Maximum distance between centers: 1,500 mm
Maximum cross feed table travel: 310 mm
Maximum tool feed table travel: 150 mm
Spindle speed range: 25 to 1500 rpm
Spindle end type: A1-8
Spindle through hole diameter: φ76 mm
Inch screw type: 40 types
Tapered tailstock hole: No. 5
Tailstock travel: 150 mm
Required floor space: 1,075 x 3,195 mm Height: 1,340 mm Machine weight: 3,200 kg
12-inch 3-jaw scroll chuck, Kitagawa JN12
Digital counter, 2 axes (scale, 3 axes, X, Z, Z2)
Fixed steady rest, 1 piece
Click on the picture for larger view.
*The machine condition shall be understood "AS IS", regardless of specifications and photos in the machine list.
