DETAIL
- Item No
0000001035
- Type
- Vertical Machining Center
- Maker
- DMG MORI
- Model
- NVX7000/50
- MFG Year
- 2013
- Movie
- Specification
- 1 2
- Comment
- Controller: FANUC‑OiMD
Table size: 1,700 × 760 mm
Maximum table load: 2,000 kg
Travel (X / Y / Z): 1,540 × 700 × 660 mm
Distance from table top to spindle nose: 200～860 mm
Spindle speed: 10,000 rpm
Tool shank: BBT‑50 (dual‑contact) MAS
Tool storage capacity: 30 tools
Required floor space: 4,280 × 3,644 mm
Machine height: 3,167 mm
Machine weight: 12,000 kg
MAPPS IV
Program memory capacity: 512 Kbyte (1280 m)
Number of registered programs: 400
Custom macro common variables: 6,600
Coordinate rotation
Relocation detection function
Click on the picture for larger view.
*The machine condition shall be understood "AS IS", regardless of specifications and photos in the machine list.
