DETAIL
- Item No
0000000998
- Type
- Vertical Machining Center
- Maker
- DMG MORI
- Model
- NVX 5080II/40 (No.NV502140107)
- MFG Year
- 2014
- Movie
- Specification
- 1 2
- Comment
- Control : MELDAS M730BM
Table size : 1,100 x 600 mm
Max. load capacity : 1,000 kg
Travel X : 800 Y : 530 Z : 510 mm
Distance from spindle end to nose : 150～660 mm
Spindle speed : 13,000 rpm
Tool shank : BBT40 (BIG Plus) MAS1
ATC : 30 stations
Required floor space : 3,314×3,613 mm
Machine height : 2,597 mm
Machine weight : 6,400 kg
In-machine coil conveyors (two, left and right)
Scraper-type chip conveyor (left rear discharge)
Tool length compensation and tool breakage detection
Touch sensor (Renishaw OMP60)
MAPPS IV
Program memory capacity: 600 m
Number of registered programs: 400
Custom macro common variables: 200
Coordinate rotation
Relocation detection function
Click on the picture for larger view.
*The machine condition shall be understood "AS IS", regardless of specifications and photos in the machine list.
