inventory

Item Numbers
Photo Machine Type ▲ ▼ Maker ▲ ▼ Model ▲ ▼ MFG Year ▲ ▼
  • BIG, NIKKEN, SHOWA,and more 切削工具、バイス、測定工具他

    Please ask for the number of stock

    Click on the picture for larger view.

  • remote visual inspection service launched!!
    New stype of physical inspection by using web meeting service like Skype, Google Hang Out, and other app.
    just sit in front of your PC, and fly to Osaka Japan in a second.
    you can also use mobile app like Viber or Wassap in case you wish to see our machine outside.

    ・you can save time & physical cost to come to Japan.
    ・motion & sound quality is outstanding as if you were visiting our warehouse in person
    ・you may also be able to finalize the deal

    just try it now!!

    ※※booking form is now available.
    please make an appointment via the inquiry form in every machine detailed page

    Click on the picture for larger view.

  • Upright Drilling Machine YOSHIDA YUD-540

    Click on the picture for larger view.

  • Upright Drilling Machine YOSHIDA YD2-55

    Click on the picture for larger view.

  • Click on the picture for larger view.

  • CNC Milling Machine SHIZUOKA VHR-AN<2022年5月完成予定機>

    Click on the picture for larger view.

  • Manual Lathe chubu CLL2500 1979

    Swing over bed:750 mm
    Swing over cross slide:435 mm
    Swing over gap:1,000 mm
    Bed length:3,875 mm
    spindle bore:φ75 mm
    Center distance:2,500 mm

    Machine weight:4,400 kg

    Steady rest

    Click on the picture for larger view.

  • Counter Machine NICOTEC NCC-400A 1988

    Click on the picture for larger view.

  • CNC Lathe DAINICHI M112×500 1991

    Swing over bed:1,120 mm
    Swing over carriage:700 mm
    Distance between centers:5,000mm
    Bed width × height:1,010 x 595 mm
    Spindle nose type:JIS A2-15
    Spindle bore dia.:φ104 mm
    Center size:1/10 meter taper No.80 75 degrees
    Spindle speed:1 ~ 500 rpm
    Both center support weight:10,000kg
    Chuck cantilever support weight:2,500kg
    Stroke X:750 Z:5,000mm
    Max. travel of tail stock spindle : 300mm
    Required floor space:2,728 x 9,065 mm
    Height:2,545 mm
    Machine weight:18,000 kg

    4-position turret
    φ1,000 4-jaw independent chuck
    Fixed stay φ50~φ350:1set、φ300~φ600:1set
    Chip conveyor included
    Threading cycle retract
    Automatic interactive programming

    Click on the picture for larger view.

  • sold out
    Double Column CNC Surface Grinder OKAMOTO DCG-4020NC 1991

    Max workpiece height:1,600mm
    Working surfface length:4,000mm
    Working surface width:2,000mm
    Max passage width:2,500mm
    Loading weight:14,000kg
    Each axis travel
    Horizontal axis grinding head(left)
    Vertical axis(Y-axis): 250mm       Front to back axis(Z-axis)
    Revolving grinding stone head (right)
    Vertical axis (V-axis): 500mm   Front to back axis (W-axis)
    Revolving axis (A-axis) : ±60°
    Virtual table NC
    Lateral axis (X-axis) : 4,500mm (4,000+500(dress))
    Horizontal axis grinding head(left)
    Grinding stone dimension :φ610×150×φ305mm
    Grinding stone speed : 940rpm
    Motor : 22KW (motor horsepower up)
    Revolving grinding stone head (right)
    Grinding stone dimension : φ305×50×φ127mm
    Grinding stone speed : 900~3,000rpm
    Motor : 7.5KW
    Cross rail balance adjusting device (operatable with control panel)
    Tape memory length 320m
    Number of control axis : 6 axes
    Simultaneous control axis : 2 axes (2 manual axes) Manual random angle feed ±30°, ±45°
    Interpolation
    Positioning Simultaneous 2 axes
    Linear interpolation Random angle   Circular interpolation Random arc 0°to 350°
    Automatic oil temperature adjusting device for hydraulic system 2 units   Desk dresser (3 direction type -45 °, 0°, +45°)※table surface
    Virtual NC control device on the left and right of table
    Oil static pressure bearing of horizontal axis grinding stone bearing
    Water filling device Tank with magnetic separator & paper filter
    Capacity : 1,500L (Including automatic water temperature adjusting device)

    Click on the picture for larger view.
